PP PE fruit vegetable seafood Knotless net making machine

Short Description:

The extruder is suitable for the continuous production of one-time forming plastic mesh net. It can produce different specifications of tube net, flat net, draft net, knotless net, boutique soft net and stretch net. These nets can be used for fruit, vegetables and alcohol packaging, bathing balls, air filtration etc.


Product Detail

Product Tags

Parameter

Model

HOTY-45

HOTY-50

HOTY-60

Raw material

PE

PE

PE

L/D

25:1

25:1

25:1

Efficiency

10-15 kg/h

15-25kg/h

25-35kg/h

Head drive

3 kw

3 kw

3 kw

Motor power

4 kw

7 kw

11kw

Screw diameter

45mm

50mm

60mm

Total weight

2T

2T

4T

Equipment dimension

10*3*2m

12*3*2m

12*3*2m

Cooling method

water cooling

water cooling

water cooling

Manpower need

1-2 person

1-2 person

1-2 person

knotless net machine (2)

working process

adwd

machine description

The extruder is suitable for the continuous production of one-time forming plastic mesh net. It can produce different specifications of tube net, flat net, draft net, knotless net, boutique soft net and stretch net. These nets can be used for fruit, vegetables and alcohol packaging, bathing balls, air filtration etc.

Extruder head and mold

Cooling water tank

Stainless steel
Water temperature: ≤60℃
Water can be recyled for cooling

Roller group

Material: steel and rubber
To make net thin and more smooth

machine (12)
c78241499ec7ed51ff3b070a643b751

Screw & barrel

The extruder screw and barrel adopts 38CrMoALA nitriding treatment. So it can have a long service life.

Control System

Electric appliances use Schneider and other brands of electrical appliances, authentic and reliable, quality assurance, international quality assurance maintenance services

sdqwd
119
81a35df251
38

Display of finished products

It is the new replacement of the traditional mesh bags,and cost only half of that.
It can produce different material and size such as a filter of top-grade appliance, the package of breeding at sea, wine, fruit,vegetable and so on.
